Pressure regulator with output pressure 50 bar - Maxireg
Single-stage high-flow pressure regulator for technical gases, designed for centralized systems and industrial applications requiring high performance. Built with a monoblock brass body and high-sealing membrane, it ensures relia… See more...
Single-stage high-flow pressure regulator for technical gases, designed for centralized systems and industrial applications requiring high performance. Built with a monoblock brass body and high-sealing membrane, it ensures reliability even under demanding conditions.
With an outlet pressure up to 50 bar and the ability to maintain a constant flow even on multiple outlets, it is ideal for:
- Centralized gas distribution systems
- Multiple welding lines
- Industrial workshops
- Supplying pneumatic tools
- Medium-pressure leak tests
- Production and maintenance in industrial environments
Standard Specifications
Construction regulations: EN ISO 2503
Input Pressure: 230 Bar Max
Output pressure: Adjustable 0/50 Bar
Flow: See Table
Usage temperature: -15 ° +60 °
Outlet Connection: G.3/8"
Hose holder diameter 6,3 mm
Manometers ISO 5171 diam. 63 mm class 2.5
HP Pressure Gauge 0/315 bar
LP Pressure Gauge 0/50 bar
Brass Body -CW617N-UNI EN 12165
High Pressure Valve Valve PVDF Valve
Brass Bell
Piston: Brass
Bronze Filter placed inside the inlet
Nb. We recommend the use of the safety valve for Oxygen
Options
Gas: O2-N2
On request connection in accordance with NF/BS/DIN
